• Weight
• Approximately 2.5 kg

• Dimensions
• 46mm × 168mm × 81mm (W×H×D)

• OPERATION SYSTEM
• Touchscreen

• Power
• AC 220V, 60Hz , 15Wmax

• IP GRADE
• N/A (Panel-mounted Type)

• Input
• Viscosity: 4 ~ 20mA, DC 24V
  Temperature: 4 ~ 20mA, DC 24V
  or Temperature: PT 100 Ω

• Output
• Viscosity: 4 ~ 20mA, DC 24V
  Temperature: 4 ~ 20mA, DC 24V
  4 ~ 20mA, DC 24V for Electric Pneumatic regulator
  4 ~ 20mA, DC 24V for valve
  220VAC, Relay for valve
  Alarm1, Alarm2
